Acoustic Grid Tiles

£0.00

A sculptural acoustic tile that drops straight into standard ceiling grids, turning an ordinary suspended ceiling into a quieter, more considered design feature.

Quantity:
Add To Cart

Acoustic grid tiles bring depth, pattern, and genuine sound control to conventional suspended ceilings. Designed to lift the look of a standard ceiling grid, these sculptural 3D panels transform an everyday functional surface into a considered design feature.  Appy as a full ceiling treatment or introduced in key areas to define zones and improve acoustic comfort over meeting and collaboration spaces.

Feature Product Collection PDF

Because they integrate directly into existing ceiling grids, they offer a simple, low-disruption way to refresh a space without the cost or upheaval of a full ceiling replacement. They are particularly effective in rooms with limited ceiling height, where suspended baffles or rafts simply aren't practical, delivering the same acoustic and visual benefit without encroaching on the space below.

For designers, they open up a new layer of texture, rhythm, and brand expression at ceiling level, an often-overlooked surface with real design potential. For clients, the result is a quieter, more comfortable environment and a more polished interior that feels intentional rather than purely functional. A ceiling that works hard, yet never dominates the space.

Specifications

Size

  • Dimensions (H × W × D): 595 × 595

  • Minimum order: 4 units

  • Order in multiples of 1 unit



Fixings

  • None

  • Optional clear silicone



Material

  • Composition: 100% PET (65% post-consumer bottle flake)

  • Fully recyclable



Fire Rating

  • EN13501: B-s1, d0



Additional Information

  • Multidirectional modular design

  • Intermediate or experienced skill level required for fitting

Product Properties

  • Optional antiviral/antimicrobial finish

  • Weight per m²: 12mm: 2.4kg

  • Semi-rigid, non-toxic, non-allergenic, non-irritating

  • Stable and easy to clean

  • Acoustic performance: Class A / E

  • Fire retardant: EN13501 B-s1,d0

  • VOC emissions: <0.02mg/m² (very low)

  • Formaldehyde: 0.00μg/g (none)

  • OEKO-TEX® Standard 100 – Class 1 (free from harmful chemicals)

Acoustic Performance

12mm Tiles:

  • No air gap: αw 0.35 / NRC 0.45 (Class E)

  • 87mm air gap: αw 0.85 / NRC 0.65 (Class C)

  • 200mm air gap: αw 1.0 / NRC 0.95 (Class A)
